Intermittent bonded ribbon production line explained
Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. supplies equipment for producing rollable formats used in optical-fiber manufacturing. Buyers can compare the capacity of this setup against their intended product range because it is designed for 12- and 16-fiber ribbons. Its split-type construction may also affect factory space and installation requirements.
Intermittent Bonded Ribbon Production Line FTTH Cable Production Line Compact Fiber Unit
For this specific production line, the specified construction speed is 600 m/min. Fiber pay-off, gathering and guiding, intermittent resin dispensing, UV-LED curing, visual monitoring, capstan pulling, and take-up are combined in the process. When assessing suitability, the entire process matters rather than speed alone.
Factory utilities, reel requirements, available floor space, and installation conditions should be assessed before purchase. Ask the supplier for its documentation package and check the system’s suitability for your cable design and operating requirements. Early planning for these details can reduce setup delays and make startup smoother.
Main Takeaways
- Designed for rollable 12- and 16-fiber formats.
- Specified equipment speed: 600 m/min.
- Features a split-type construction.
- Curing, monitoring, pulling, and take-up stages are included.
- Check utilities, reels, installation needs, and supplier documents before buying.
Intermittent Bonded Ribbon Production Line
Examine The Intermittent Bonded Ribbon Production Line
To create rollable IBR formats, three mold groups position fibers for the application of small adhesive dots. Mold position is adjustable by operators from 0 to 15 mm, helping maintain consistent spacing and form.
Make Rollable Fiber Ribbons Using Precision Bonding
The machine is fed by a 16-spool pay-off, and guide rollers with U-shaped grooves help maintain the organization of each strand. Hard-anodized roller surfaces support steady contact during processing. For 12F and 16F layouts, the adjustable valve setup uses 5+5+1 valves for 12 fibers or 5+5+5 for 16. Confirm the appropriate tension control settings with the supplier for your cable design.
Run 12- And 16-Fiber Configurations At Up To 600 m/min
The stated construction speed is up to 600 m/min. Pay-off reel options hold 25.2 km or 50.4 km of fiber according to the listed reel dimensions: Φ236 mm × Φ25.4 mm × 108 mm and Φ267 mm × Φ25.4 mm × 180 mm. The system also provides T-type or fiber-optic take-up reels. Compare reel capacity with your production requirements and expected changeover time.
Review The Production Line’s Key Equipment And Controls
Tension, resin placement, and UV exposure must work together to deliver reliable output. Operators can use the system to align settings with the needs of their cable design and fiber ribbon.
Manage Fiber Tension, Resin Dispensing, And UV-LED Curing Together
Electro-pneumatic adjustment is used for each pay-off unit. Through the interface, operators set adhesive-dot spacing and counts while dispensers work individually or in linked groups.
Three pre-curing ovens support the mold groups ahead of UV-LED post-curing. Verify resin compatibility and operating conditions with the supplier.
Lamp current, oven temperature, alarms, and preset lengths are monitored or managed through the Siemens PLC and touchscreen. Check the necessary cabinet and power supply arrangements before purchasing.
| Process Stage | Technical Specification | Buyer verification |
| Tension of fibers | Pay-off tension: 0.4 to 2 N with ±0.02 N; capstan tension: 50 to 500 g with ±5 g accuracy | Match settings to cable needs |
| Resin dispensing | Individually operated or linked units with adjustable adhesive-dot spacing and count | Review interface settings |
| UV-LED curing | Three pre-curing ovens rated 800 W each; one post-curing oven rated 6 kW; 395 nm ± 3 nm; at least 85% cure during stable, high-speed operation | Verify compatibility with the resin |
| Monitoring | Siemens S7-1200 or S7-1500 PLC; 10.4-inch touchscreen; live lamp current and oven temperature, alarms, preset lengths | Check cabinet and power supply |
Prepare Line Configuration, Installation, And Operating Conditions
Prepare a dedicated area before the equipment arrives. An enclosed, clean, dry, draft-free space is required for the optical fibre system. Maintain temperatures between 15°C and 25°C and humidity at or below 85%. Maintaining these conditions helps preserve equipment protection and operating precision.
With your facilities team, check site utilities, available electrical capacity, cabinet space, and cable design. The system needs nitrogen supplied at 7 bar and 99.99% purity, together with compressed air at 6 bar. The electrical supply must be three-phase, five-wire, and 380 V ±10%.
- Allow space for the cabinet, components, resin, and access to service parts. Verify temperature settings and tension control before startup.
- Account for the specified reel size of Φ410 mm × Φ50.8 mm × 391 mm. The take-up unit supports reels weighing up to 30 kg.
- Include the main power feed-in cable in your site plan. Connection cables and cable trays are not included with the equipment.
Before ordering, confirm the supply scope, reel types, and installation requirements. This assessment can shorten setup time and help prevent later delays. Request supplier confirmation of appropriate settings for your fiber and cable design, including lamp accuracy and operating conditions. A clear plan helps the production system start more smoothly.
Obtain Pricing For A Ribbon Production Solution Matched To Your Needs
At its stated speed of 600 m/min, this line can be considered by manufacturers producing rollable 12- or 16-fiber formats. When requesting a quote, provide your fiber layout, output goals, cable requirements, reel preference, and factory conditions.
Confirm that the proposed system includes the 16-spool pay-off, UV-LED curing arrangement, take-up capacity, and relevant options. Examine the included components, dispensing-head options, unit functions, and cable design prior to ordering.
Listed documents include operating and maintenance manuals, a general layout drawing, electrical schematics, and a wear-parts list. These documents can help understand setup time and ongoing service needs.
For pricing and configuration details matched to your production plan and site utilities, contact Shanghai Weiye Optic Fiber Communication Equipment Co., Ltd. Verify the supply scope and replacement parts before purchase.
